| Atmosphere temperature | -20℃-+40℃ |
| Altitude | ≤1000m |
| Voltage | 380v |
| Frequency | 50Hz |
| Insulation class | F |
| Degrees of protection | IP66 |
| Duty | S1 |
| Cooling methods | 1c410 |
| Installation direction | Horizontal |
Characteristics
1. Reasonable design, excellent material, high efficiency, low temperature rise, long service life;
2. Simple transmission structure, lower power consumption, electrical power can be saved , easy installation and maintenance
3. The weight density and design this vibratory motor has a good vibratory output force (kN) with a high starting torque and good synchronizing performance;
4. Low operating noise levels (dB)due to stable rotation.
5. By adjusting the angle of the flyweights,various vibratory Or increase and decrease the flying-weights force can be achieved;
6. Single or multiple motors can be combined into various vibration farms to meet various operating requirements.
Application
Material Handling: Conveyors, feeders, and screens in mining, quarrying, and recycling industries.
Construction: Compaction equipment, concrete vibrators, and formwork systems.
Food and Pharmaceutical: Sieving, sorting, and processing equipment in food processing and pharmaceutical industries.
Manufacturing: Production machinery for compacting, settling, and polishing processes.
Agriculture: Seed and grain handling equipment, soil compactors, and agricultural machinery.
Packaging: Vibratory feeders and compactors in packaging lines.
Environmental: Waste handling and recycling equipment.
Automotive: Vibration testing equipment and manufacturing processes in automotive production.
Chemical and Petrochemical: Mixing, sieving, and processing equipment in chemical and petrochemical industries.
Ordering Information
● This catalogue is for the user's information only. Please excuse that if there are any changes to the product, no additional notes will be made in advance.
● When ordering, please note the rating data, such as motor type, power, voltage, speed, insulation class, protection class, mounting method, etc.
● We can design and manufacture special motors according to customer requirements as follows
1. Special voltages, frequencies and powers
2. Special insulation and protection classes
3. With left-hand terminal box, double shaft ends and special shafts
4. High temperature motors or low temperature motors.
5. Highland or outdoor use
6. Higher power or special service factors
7. With heating, bearings or windings pt100, ptc, etc.
8. With encoder, isolated bearings or isolated bearing construction.
9. Other requirements.
