NF series large swimming pool filter pump

Features:

1. Compact structure and small volume. The vertical pipeline pump occupies a small area. The inlet and outlet diameters are the same and on the same center line. It can be installed on the pipeline like a valve. The center of gravity of the pump coincides with the center of gravity of the pump feet, which enhances the operation stability of the pump. performance and service life.

2. The coaxial design of the machine and pump makes the pump operate with little vibration and noise, prolongs the service life of the bearings and improves the use environment.

3. The seal uses fluorine rubber, and the mechanical seal can be replaced with PTFE mechanical seal according to customer needs. The motor adopts a high-efficiency heat dissipation cast aluminum casing, a stainless steel 316 welded rotor shaft, and all flow-passing parts are made of stainless steel;

4. Easy maintenance, no need to disassemble the pipeline. Just remove the connecting frame and take out the motor and transmission components for inspection and maintenance.
