| Frame Size | H71--H355 |
| Rated Power | 0.37 KW - 375 KW |
| Rated Voltage | 380 V |
| Rated Frequency | 50 Hz/60 HZ |
| Degrees of Protections | IP55 |
| Degrees of insulation/Temperature rise | F/B |
| Installation Method | B3; B5; B35; V1 |
| Ambient temperature | -15°C ~+40°C Relative humidity should be less than 90% Altitude should be lower than 1000 m above sea level |
| Cooling Method | IC411, IC416, IC418, IC410 |
Characteristics
High Efficiency: Motors ranging from IE1 to IE4 levels exhibit high energy efficiency, with IE4 being the most efficient.
Reliability: These motors are typically designed with rugged and durable cast iron construction, offering good mechanical strength and thermal stability, ensuring reliable operation in various harsh environmental conditions.
Low Noise and Vibration: Due to precision design and manufacturing processes, these motors operate with low noise and vibration, providing smoother operation.
Strong Adaptability: They can adapt to different working conditions and environments, including high temperature, humidity, and corrosive gases.
Ease of Maintenance: Simple design and compact structure make them easy to maintain and repair.
Application
Industrial Applications:
Including pumps, fans, compressors, conveyor machinery, etc., used in various industrial scenarios such as factory production lines, manufacturing, and so forth.
Construction Industry:
Used for driving building equipment such as elevators, air conditioners, water pumps, etc.
Agricultural Sector:
Utilized in agricultural machinery and equipment, such as water pumps, irrigation systems, feed machinery, etc.
Transportation:
Including electric vehicles, rail transportation systems, etc.
Energy Industry:
Used in various energy equipment such as generators, water pumps, fans, etc.
Ordering Information
● This catalogue is for the user's information only. We apologise for not giving advance notice of any product changes.
● When ordering, please specify the motor type, power, voltage, speed, insulation class, protection class, mounting method, etc.
● We can design and manufacture special motors to customer requirements as follows:
1. Special voltage, frequency and power.
2. Special insulation and protection classes.
3. With left hand terminal box, double shaft ends and special shafts.
4. High temperature or low temperature motors.
5. High altitude or outdoor use.
6. Higher power or special service factors.
7. With heating, bearings or windings PT100, PTC, etc.
8. With encoder, isolated bearings or isolated bearing construction.
9. Other requirements.
