The relationship between no-load current for motors with the same power but different pole numbers:

Impact of Pole Number on No-Load Current in Motors

The no-load current refers to the current when the motor is not driving a load. To describe the size of the no-load current, the proportion of no-load current relative to the rated current is often used for comparative analysis. Thus, we start the discussion from the relationship of rated current. From the formula relating the rated power, rated voltage, and rated current of a three-phase asynchronous motor,

Impact of Pole Number on No-Load Current in Motors

it is clear that when the motor’s rated power and rated voltage are the same, the size of the rated current depends on the motor's efficiency and power factor. From the technical specifications of motor products, for the same rated power and rated voltage, low-speed, multipole motors generally have lower efficiency and power factor. Furthermore, the difference in power factor is more noticeable than that of efficiency when comparing motors with a large pole number difference. Based on this, we can deduce from the relationship formulas that motors with more poles will have a larger rated current. For motors with the same power but different poles where efficiency differences are minor, the primary distinction lies in the power factor.

Impact of Pole Number on No-Load Current in Motors

Most of the no-load current in a motor is used to create a rotating magnetic field, with its size being very close to the excitation current, which essentially determines the size of the no-load current. In the motor current parameter calculation formulas, the size of the excitation current is positively correlated with the number of pole pairs in the motor. Although other parameters also affect it, the influence of pole pairs is more significant. Therefore, under the same power conditions, low-speed motors generally have a larger no-load current. Given the relationship between rated current and excitation current, this serves as a theoretical basis for the higher no-load current in multipole motors.

Impact of Pole Number on No-Load Current in Motors

For example, in three-phase asynchronous motors, the no-load current of a 2-pole motor is generally about 30% of the rated current, while that of an 8-pole motor can reach 50-70% of the rated current. For some special-purpose motors, the no-load current may be close to the load current. Thus, by examining the size of the no-load current, we can qualitatively determine the motor's performance level. However, given the interrelationships between various parameters, it is not advisable to evaluate one parameter or performance purely based on the size of another.

Impact of Pole Number on No-Load Current in Motors
