12V 1623 Motor for ABS Pump ZDY1623

1. The wires and terminal is anti-flamed material VO, and the motor is anti-watered, IP(X)7

2. Environment requirements:

a. Elevation under 4000m

b. Temperature:-40~120

c. Humidity:95%

d. When the elevation not exceed 1000m, rasing of the temperature can't be 50K or more.

3. The frame of the motor is casting Aluminum. tracing code attached.

4. The working time:1000h, no-load noise 55dB

5. Shaft GCr15 quench hardness: HRC45-55

The motor ZDY1623 is a motor well known of the quality and more, for this aspect, we did have a mature inspection process in our workshop, the particular report, and complete exam.
